BFT Icaro Veloce Smart AC A1000 Sliding Door Motor is a special series sliding door motor with a capacity of 1000 kg, suitable for intensive use, opening and closing at high speed. It has a D-Track dynamic path tracking feature. (Smart torque management system that constantly updates the door torque level and improves maneuverability regardless of weather conditions, temperature or degree of wear in the system.) The gear inside is protected against heating and wear with the mechanism we call the continuous oil bath.



Learn More


Teknik Özellikler:

Kumanda santrali: LEO B CBB SV

Kart beslemesi: 230V

Kullanılan elektrik gücü: 750W

Pinyon modülü: 4 mm (25 diş)

Kanat hızı: 25 m/dakika

Kilitleme: Mekanik Kilit

Manuel manevra: Kollu mekanik serbest bırakma mekanizması

Koruma derecesi: IP24

Çevre koşulları: -15 ÷ 55°C

Ara bağlantısallık: Evet

Maks. kapı/bahçe kapısı ağırlığı: 1000KG

Maks. tork: 40Nm

Darbe tepkisi: 8K2 güvenlik kenarı (ürünle verilmez)

Kullanım sıklığı: Çok yoğun

Yavaşlatma: Evet

Motor gerilimi: 230V
